The ELECTRA 6mm² SDI Red Cable is a robust, flexible single-core electrical cable made for safe and effective power transmission in residential, commercial, and industrial environments. It has great conductivity and flexibility because it is made using stranded annealed copper conductors. The cable is protected by a durable PVC outside sheath (3V90) and insulated with heat-resistant PVC (V90) to provide long-lasting durability and safety. It is rated for 450/750 volts, complies with Australian standards AS/NZS 1125 and AS/NZS 5000. 2, and is safe to use in temperatures as high as 90°C.
Characteristics:
Conductor Size: 6 mm² for moderate current loads.
Stranded annealed copper is the material used for the conductor because it is flexible and has excellent electrical conductivity.
Insulation: Heat-resistant V90 PVC insulation.
Sheath: Tough PVC outer sheath (3V90) for mechanical defense.
Voltage Rating: 450/750V, ideal for a range of electrical circuits.
Temperature Range: Safe operation up to 90°C.
Primary Color: Red for simple identification.
Ideal for large installations, the rolls are 100 meters long.
Adherence: In accordance with the Australian standards AS/NZS 1125 and AS/NZS 5000. 2.
Applications: Appropriate for use in industrial settings, business structures, and home wiring
Applications:
This cable may be used in a wide range of electrical applications, such as:
Home Wiring: Lighting and power circuits.
Business establishments include retail spaces, offices, and other commercial structures.
Industrial Applications: Industrial facilities and factories.
| Specification |
Details |
| Product Name |
Electra 6mm² Red SDI Cable 100m |
| Model Number |
SDI1060V |
| Conductor Size |
6 mm² |
| Conductor Material |
Stranded annealed copper |
| Insulation Material |
PVC V-90 |
| Sheath Material |
3V-90 PVC |
| Core Colour |
Red |
| Sheath Colour |
White |
| Voltage Rating |
450/750V |
