The Electra 6mm² Black SDI Cable is a high-performance, double-insulated single core cable made for reliable electrical installations. It is rated for 450/750V and can tolerate temperatures of up to 90°C. This cable is ideal for a broad range of residential, commercial, and industrial applications because it is made of high-quality stranded annealed copper, which provides outstanding conductivity and durability, and is protected by V90 PVC insulation and a 3V90 PVC jacket.
Characteristics:
Conductor Size: 6 mm2 – adequate for moderate current loads.
Material: High-conductivity stranded annealed copper for flexibility and performance.
Insulation: Superior thermal and electrical resistance provided by V90 PVC insulation.
Sheath: A 3V90 PVC sheath for increased strength and defense.
Voltage Rating: 450/750 V – Meets popular power distribution standards.
Temperature rating: Operates safely up to 90°C.
Color Identification: Use the black core to identify the clear phase.
Length: The 100-meter roll is ideal for large-scale wiring.
Meets the requirements of AS/NZS 1125 and AS/NZS 5000. 2.
Application: Appropriate for use in residential, commercial, and industrial environments.
Applications:
This cable is appropriate for a number of electrical applications, such as:
Home Wiring: Lighting and power circuits.
Commercial Installations: retail establishments, offices, and other business structures.
Industrial Applications: Manufacturing facilities and factories.
| Specification |
Details |
| Product Name |
Electra 6mm² Black SDI Cable 100m |
| Model Number |
SDI1060V |
| Conductor Size |
6 mm² |
| Conductor Material |
Stranded annealed copper |
| Insulation Material |
V-90 PVC |
| Sheath Material |
3V-90 PVC |
| Core Colour |
Black |
| Sheath Colour |
White |
| Voltage Rating |
450/750V |
