The ELECTRA 10mm² SDI Red Cable is a strong and versatile single-core electrical cable made for hardwiring in residential, commercial, and industrial settings. Its superior thermal and electrical resistance is due to its construction using stranded annealed copper conductors and its insulation using robust V90 PVC. The outer PVC coating offers further protection against mechanical harm and environmental elements. This cable has an AS/NZS rating for 450/750 volts and may be used at temperatures as high as 90°C with assurance of safety and dependability.
Features:
10 mm² is the conductor size, which has a respectable current-carrying capacity.
Material: Stranded annealed copper for flexibility and excellent conductivity.
Insulation: Heat resistance and electrical safety provided by V90 PVC insulation.
Sheath: A robust outer sheath made of 3V90 PVC that provides mechanical protection.
Voltage Rating: 450/750V, which works well with a wide range of electrical setups.
Temperature Range: Safe operation up to 90°C.
Red is the core color, which makes it simple to recognize in cable installations.
Roll length: 100 meters, making it perfect for large-scale wiring projects.
Adherence to Australian standards AS/NZS 1125 and AS/NZS 5000. 2.
Applications: Ideal for use in commercial, industrial, and residential power circuits.
Applications:
This cable is appropriate for a wide range of electrical applications, such as:
Household Wiring: Lighting and power circuits.
Retail establishments, offices, and other commercial facilities are examples of commercial installations.
Industrial Applications: Factories and industrial facilities.
| Specification |
Details |
| Product Name |
Electra 10mm² Red SDI Cable 100m |
| Model Number |
SDI1100V |
| Conductor Size |
10 mm² |
| Conductor Material |
Stranded annealed copper |
| Insulation Material |
PVC V-90 |
| Sheath Material |
3V-90 PVC |
| Core Colour |
Red |
| Sheath Colour |
White |
| Voltage Rating |
450/750V |
