The ELECTRA 2. 5mm² SDI Red Cable is a robust and versatile single-core electrical cable made to provide dependable power in domestic, commercial, and industrial applications. It has a premium simple annealed copper conductor that guarantees outstanding electrical conductivity. The cable may be used in environments where mechanical and thermal protection is required since it is shielded by a robust 3V90 PVC sheath and insulated with heat-resistant PVC V90 insulation. This cable has received Australian Standards AS/NZS 1125 and AS/NZS 5000. 2 certification for safety and performance. It can withstand temperatures of 90°C and is rated for 450/750 volts.
Highlights:
Conductor Size: 2. 5 mm2
Plain annealed copper (AS/NZS 1125) is used for the conductor material because of its dependable conductivity.
Insulation: Heat-resistant PVC V90 insulation to ensure safety and longevity.
Covering: A protective 3V90 PVC covering that guarantees resistance to mechanical and environmental harm.
Voltage rating: 450/750 V, which is compatible with several different electrical circuits.
Red is the primary color for easy identification.
White is the color of the sheath.
Operating temperature: The rated temperature is up to 90°C for safe use.
Length: 100 meters each roll, perfect for large-scale cabling needs.
Compliance: Satisfies the criteria set forth by AS/NZS 1125 and AS/NZS 5000. 2, guaranteeing excellence and security.
Applications:
This wire may be used for a wide range of electrical applications, such as:
Household wiring: lighting and electrical circuits.
Commercial installations include retail establishments, offices, and other commercial structures.
Factories and other manufacturing establishments are examples of industrial applications.
Ideal for electrical wiring applications in homes, businesses, and industries.
| Specification |
Details |
| Product Name |
Electra 2.5mm² Red SDI Cable 100m |
| Model Number |
SDI1025V |
| Conductor Size |
2.5 mm² |
| Conductor Material |
Plain annealed copper (AS/NZS 1125) |
| Insulation Material |
PVC V-90 |
| Sheath Material |
3V-90 PVC |
| Core Colour |
Red |
| Sheath Colour |
White |
| Voltage Rating |
450/750V |
