Features:
Conductor Size: 16 mm2 - appropriate for applications requiring a high current carrying capacity.
Material: Stranded annealed copper, which guarantees flexibility and high conductivity.
Insulation: V90 PVC, which offers protection against heat, abrasion, and electrical issues.
3V90 PVC Sheath: Sturdy outside protection for mechanical safety.
Red is the core color, which is perfect for spotting active/live wiring.
Voltage Rating: 450/750V, in accordance with common electrical installation standards.
Applications:
This cable is compatible with a wide range of electrical applications, such as:
Household Wiring: Lights and power circuits.
Retail locations, offices, and other business establishments are examples of commercial installations.
Factories and industrial facilities are examples of industrial uses.
Temperature Rating: Safe operation up to 90°C.
Roll length: 100 meters, which is perfect for large installations.
Standards Compliance: Meets Australian safety and performance requirements as outlined in AS/NZS 1125 and AS/NZS 5000. 2.
Applications: Ideal for fixed cabling in residential, commercial, and industrial settings.
Household Electrical Wiring: Power circuits and illumination.
Commercial Installations: offices, stores, and other commercial establishments.
Factories and other industrial facilities are examples of industrial uses.
| Specification |
Details |
| Product Name |
Electra 16mm² Red SDI Cable 100m |
| Model Number |
SDI1160V |
| Conductor Size |
16 mm² |
| Conductor Material |
Stranded annealed copper |
| Insulation Material |
PVC V-90 |
| Sheath Material |
3V-90 PVC |
| Core Colour |
Red |
| Sheath Colour |
White |
| Voltage Rating |
450/750V |
| Operating Temperature |
Up to 90°C |
