The ELECTRA 1. 5mm² SDI Red Cable is a single-core electrical cable intended for the secure and dependable delivery of electricity in household, commercial, and industrial settings. It has a high-quality simple annealed copper conductor for superb electrical conductivity. The cable is shielded from mechanical damage and environmental hazards by a robust 3V90 PVC jacket and heat-resistant PVC V90 insulation. This cable complies with the rigorous Australian standards AS/NZS 1125 and AS/NZS 5000. 2, is rated for 450/750 volts, and can be used safely at temperatures of up to 90°C.
Features:
Size of the conductor: 1. 5 mm²
Simple annealed copper, according to the AS/NZS 1125 standard, is used as the conductor material.
Insulation: For increased safety, use heat-resistant PVC V90 insulation.
Sheath: Durable and mechanically protective 3V90 PVC sheath.
Voltage rating: 450/750V, compatible with a wide range of electrical applications.
Red is the main hue for simple identification.
White is the color of the sheath.
Rated up to 90°C for operating temperature.
Each roll is 100 meters long.
Compliance: Made in accordance with the requirements of AS/NZS 1125 and AS/NZS 5000. 2.
Appropriate for usage in residential, commercial, and industrial wiring applications.
Applications:
This cable is appropriate for a wide range of electrical installations, such as:
Home Wiring: Lighting and power circuits.
Commercial Facilities: Retail establishments, offices, and other commercial structures.
Industrial Use: Industrial facilities and factories.
| Specification |
Details |
| Product Name |
Electra 1.5mm² Red SDI Cable 100m |
| Model Number |
SDI1015V |
| Conductor Size |
1.5 mm² |
| Conductor Material |
Plain annealed copper (AS/NZS 1125) |
| Insulation Material |
PVC V-90 |
| Sheath Material |
3V-90 PVC |
| Core Colour |
Red |
| Sheath Colour |
White |
| Voltage Rating |
450/750V |
