The Electra 16mm² Black SDI Cable 100m is a premium double-insulated single-core electrical cable made to deliver dependable power in a variety of applications. This cable is ideal for use in residential, commercial, and industrial environments because of its stranded annealed copper conductor and sturdy PVC insulation. Its strong build guarantees durability and safety, making it ideal for direct burial, underground ducts, or conduits where mechanical protection is not necessary.
Characteristics:
Size of Conductor: 16 mm2 – ideal for applications involving high current.
Material: High-conductivity annealed copper for maximum electrical efficiency.
Insulation: Long-lasting V90 PVC insulation for excellent electrical and thermal resistance.
Color: The core is black for simple phase identification.
Voltage Rating: Rated for usage at 450/750V.
Temperature Range: Can endure temperatures up to 90°C.
Length: Available in 100-meter rolls, ideal for large-scale electrical projects.
Construction: Stranded conductor increases flexibility for simpler installation.
Applications: Can be used in industrial, commercial, and residential wiring systems.
Compliance: Satisfies the quality and safety criteria established by the AS/NZS 1125 and AS/NZS 5000. 2 standards.
Applications:
The following are some of the possible electrical applications for this cable:
Household wiring includes lighting and electricity circuits.
Offices, retail establishments, and other commercial structures are examples of commercial installations.
Industrial Uses: Factories and industrial facilities.
| Specification |
Details |
| Product Name |
Electra 16mm² Black SDI Cable 100m |
| Model Number |
SDI1160V |
| Conductor Size |
16 mm² |
| Conductor Material |
Stranded annealed copper |
| Stranding |
1 x 7/1.7 mm (7 strands of 1.7 mm diameter) |
| Insulation Material |
V-90 PVC |
| Sheath Material |
3V-90 PVC |
| Core Colour |
Black |
| Sheath Colour |
White |
