Features:
Conductor Size: 2. 5 mm2.
High-purity annealed copper is used as the conductor material because it has excellent conductivity.
Insulation: Tough PVC insulation for extra protection and safety.
Voltage Rating: Ideal for use in applications with a maximum voltage range of 450/750 volts.
Red is the color, making it simpler to see during installation.
Length: Comes in a 500 meter reel, which is perfect for major projects.
Compliance: Produced in accordance with Australian Standards to guarantee dependability and safety.
Applications: Ideal for industrial, commercial, and residential electrical installations.
Applications:
This cable is appropriate for a wide range of electrical installations, such as:
Home Wiring: Lighting and power circuits.
Commercial Installations: Retail establishments, offices, and other commercial structures.
Applications in Industry: factories and industrial facilities.
Specification |
Details |
Product Name |
Electra 2.5mm² Red SDI Cable 500m |
Conductor Size |
2.5 mm² |
Conductor Material |
Annealed Copper |
Stranding |
1 x 7/0.67 mm (7 strands of 0.67 mm diameter) |
Insulation Material |
V-90 PVC |
Insulation Thickness |
0.7 mm |
Sheath Material |
3V-90 PVC |
Sheath Thickness |
0.8 mm |
Core Colour |
Red |
