This 16 mm² Electra building wire is a strong and dependable cable composed of high-grade tinned copper and covered with sturdy PVC V90 insulation. Because it is designed to withstand voltages of up to 1,000 volts, it is a suitable option for electrical tasks where wires are buried or difficult to reach, such as within switchboards or control panels. It is particularly well suited for installations where cables must enter glands safely.
Principal attributes:
Robust Conductor: Consisting of seven strands of 1. 7mm tinned copper, providing outstanding conductivity and corrosion resistance.
Strong Insulation: Complies with AS/NZS 3808 and is protected by PVC V90, ensuring longevity and safety.
High Voltage Handling: Rated for up to 0. 6/1kV, making it ideal for home, business, or industrial electrical requirements.
Heat-Resistant: Designed to tolerate temperatures up to 90°C, making it suitable for use in hot climates.
Meets Australian standards AS/NZS 1125 and AS/NZS 5000. 1.
Color Choices: To complement any wire arrangement, it comes in black, red, blue, white, and green/yellow (earth) colors.
Handy Length: The 100-meter roll makes it simple to cut and install as necessary.
Specification |
Details |
SKU |
SR1160 |
Color |
Red |
Cable Size |
16mm² |
Stranding |
7/1.7mm |
Overall Diameter |
Approximately 7.1mm |
Minimum Bend Radius |
30mm |
Insulation Material |
PVC V90 |
Conductor Material |
Tinned Copper |
Voltage Rating |
0.6/1 kV |
Operating Temperature |
Up to 90°C |
Standards Compliance |
AS/NZS 1125, AS/NZS 5000.1, AS/NZS 3808 |
