With its plain annealed copper conductor and robust V90 PVC insulation, the ELECTRA BLACK 10MM2 BUILDING WIRE SR1100 100M is a fantastic single-core electrical cable that can be used in a wide range of construction and electrical applications, including general wiring and challenging conditions. It's often employed inside other enclosed equipment where the cable is difficult to access without tools, as well as for independent earth conductors, switchboard and control panel wiring. Its production adheres to the applicable norms in Australia and New Zealand, guaranteeing dependability and safety.
Essential characteristics:
Use bare annealed copper (typically 7/1. 35mm stranding) as the conductor material for optimum conductivity.
V90 PVC (polyvinyl chloride) insulation, which is well-known for its strength and heat resistance. In addition, certain publications make mention of V90HT, which indicates a higher temperature grade.
With a voltage rating of 0. 6/1 kV, it is appropriate for the majority of residential, commercial, and industrial electrical systems.
Temperature Rating: It is designed to operate at a standard operating temperature of up to 90°C.
Adherence: Meets Australian and New Zealand standards, including AS/NZS 1125, AS/NZS 3808, and AS/NZS 5000. 1.
Color: Black insulation, ideal for distinguishing various circuits, particularly when it comes to neutral or specific phase wiring in accordance with local regulations.
Length: Available in a convenient 100-meter coil or roll.
Use: Ideal for glanding as well as for machinery like control panels, switchboards, and enclosed wiring where the cable is not vulnerable to physical damage.
Specification |
Details |
Model Number |
SR1100 |
Conductor Size |
10 mm² |
Stranding |
7 strands of 1.35 mm |
Overall Diameter |
6.1 mm |
Insulation Thickness |
1.0 mm |
DC Resistance |
1.83 Ohm/km |
AC Resistance |
2.23 Ohm/km |
Standards Compliance |
AS/NZS 1125, 3808, 5000.1 |
Voltage Rating |
0.6/1 kV |
Current Rating |
Around 53 Amp |
