The ELECTRA EARTH 10MM2 BUILDING WIRE SR1100 100M is a superb singlecore electrical cable for a wide range of electrical and construction uses. It has a plain annealed copper conductor with long-lasting V90 PVC insulation, making it ideal for harsh environments and general cabling. It is often used in switchboards and control panel cabling, as well as in other enclosed equipment where the cable cannot be accessed without the use of tools, and for separate earth conductors. It is made in accordance with all applicable Australian and New Zealand standards, ensuring safety and reliability.
Essential features include:
Use bare annealed copper (typically 7/1. 35mm stranding) as the conductor material for greater conductivity.
polyvinyl chloride (PVC) insulation known as V90 PVC, which is well-known for its durability and heat resistance. Furthermore, V90HT, which indicates a higher temperature rating, is mentioned in a few publications.
The voltage rating of 0. 6/1 kV makes it appropriate for most household, commercial, and industrial electrical systems.
Temperature Rating: The typical operating temperature for which it is designed to operate is up to 90°C.
Adherence: Meets Australian and New Zealand Standards, including AS/NZS 1125, AS/NZS 3808, and AS/NZS 5000. 1.
Earth isolation is ideal for distinguishing between various circuits, particularly for neutral or certain phase cabling in accordance with local regulations.
Length: Available as a useful 100 meter coil or roll.
Ideal applications include equipment where the wire is protected from mechanical damage, such as control panels, switchboards, and enclosed cabling. Perfect for glanding too.
Specification |
Details |
Model Number |
SR1100 |
Conductor Size |
10 mm² |
Stranding |
7 strands of 1.35 mm |
Overall Diameter |
6.1 mm |
Insulation Thickness |
1.0 mm |
DC Resistance |
1.83 Ohm/km |
AC Resistance |
2.23 Ohm/km |
Standards Compliance |
AS/NZS 1125, 3808, 5000.1 |
Voltage Rating |
0.6/1 kV |
Current Rating |
Around 53 Amp |
