Superior construction wire features a single-core, stranded copper conductor and durable V90 PVC insulation. It works well for fixed wiring in homes, commercial establishments, and factories. Whether you're dealing with switchboards, control panels, or power distribution, this wire ensures reliable operation and safety. You can rely on it for dependable electrical installations since it complies with AS/NZS 5000. 1.
Main Attributes:
Robust Copper Structure: Strand annealed copper (7 0. 50 mm strands) for durability and flexibility.
Excellent Insulation: Surrounded by V90 PVC insulation, which can withstand temperatures up to 90°C.
The optimal rating for most low-voltage electrical systems is a voltage of 0. 6/1 kV.
Current Capability: Successfully handles up to 16 Amps.
Color: A chic shade of blue finish.
Length: It comes on a convenient roll of 100 meters.
Compliant with Standards: Complies with the safety and quality criteria established by AS/NZS 5000. 1, AS/NZS 3808, and AS/NZS 1125.
| Specification |
Details |
| SKU |
SR1015 |
| Color |
Blue |
| Conductor Size |
1.5 mm² |
| Stranding |
7/0.50 mm |
| Insulation Thickness |
0.8 mm |
| Overall Diameter |
3.1 mm |
| Minimum Bending Radius |
15 mm |
| Conductor Resistance (DC) |
13.6 Ohm/km |
| Conductor Resistance (AC) |
16.5 Ohm/km |
| Operating Temperature |
Up to 90°C |
| Weight |
Approximately 2.135 kg per roll |
