Combined Protection: Integrates overcurrent protection and earth leakage protection into a single device, reducing the need for separate MCBs and RCDs.
Type A RCD: Suitable for detecting both AC and pulsating DC residual currents, making it ideal for modern electrical installations with electronic devices.
C-curve Tripping: Provides delayed tripping, allowing brief inrush currents (e.g., from motors) without nuisance tripping.
High Short-Circuit Breaking Capacity: Rated at 6kA, this RCBO can handle and interrupt fault currents as high as 6,000A, ensuring safe disconnection in the event of short-circuit faults.
Compact Design: 4 modules wide, facilitating space-saving installations on DIN rails.
Test Function: Equipped with a test button to verify the functionality of the RCD component.
FEATURES:
Screw Terminal Connections: For easy and secure wiring, the device comes with screw terminals that accommodate both flexible and rigid conductors.
Residential Installations: Protecting circuits supplying power to household appliances and lighting.
Commercial Buildings: Safeguarding circuits in offices, shops, and other commercial establishments.
Industrial Applications: Protecting machinery and equipment from electrical faults.
Distribution Panels: Providing combined overcurrent and earth leakage protection in main and sub-distribution boards.
| Feature | Specification |
|---|---|
| Model | Hager ADM425T |
| Poles | 4 |
| Rated Current | 25A |
| Rated Residual Operating Current | 30mA |
| Rated Short-Circuit Breaking Capacity | 6kA |
| Rated Operational Voltage | 230/400V AC |
| Frequency | 50 Hz |
| Mounting | DIN rail |
| Protection Class | IP20 |
| Operating Temperature Range | -25°C to +40°C |
| Dimensions (H x W x D) | 84mm x 71mm x 70mm |
| Terminal Connection | Screw terminals |
| Test Function | Yes |
